Forge Series · Pin-Select MODEL: HS05 Lateral Raise

HS05 Lateral Raise

A dedicated commercial lateral raise machine engineered for precise deltoid isolation and shoulder width development. Features a natural lateral arc, 96 kg weight stack, and commercial-grade construction for serious shoulder training.
Retail Price
$2,895.00 MSRP · Request quote for bulk pricing
Wholesale pricing available — Apply for partner access

Bulk Pricing Available

  • Buy 3+ and save 5% 3–4 units — 5% off
Unit Price $2,895.00
Subtotal $2,895.00
Estimated Quote Total $2,895.00

Final pricing will be confirmed in your custom quote.

233kg
Machine Weight
96kg+4.6kg
Weight Stack
Pin-Select
Type
Commercial Grade Build
Warranty Included
Ships from Tulsa, OK
Key Features
  • Dedicated lateral raise for precise medial deltoid isolation
  • Natural lateral arc for biomechanically correct shoulder abduction
  • Consistent resistance from starting position to peak abduction
  • 96 kg weight stack with 4.6 kg fine-tune increments
  • Built for shoulder width, deltoid definition, and upper body aesthetics
Machine Specifications
Model Number HS05 Lateral Raise
Series Forge Series
Equipment Type Pin-Select
Machine Weight 233kg
Weight Stack 96kg+4.6kg
Dimensions 1100×1000×1630mm
Packing Size 1720×820×420mm
Muscle Group Deltoids, Medial Deltoid, Lateral Deltoid, Trapezius, Supraspinatus
Construction & Materials
Frame Material 11 Gauge Steel
Frame Finish Powder Coated (9 colors)
Upholstery Commercial Vinyl (10 colors)
Cable Type Aircraft Grade Steel Cable — Japanese Import, 189-wire, Rubber Coated
Seat Adjustment Fixed Position
Min. Ceiling 2400 mm / 94 in
Warranty Commercial Warranty — Contact for Terms. 3 Year Frame, 1 Year Parts, 1 Year Upholstery

The HS05 Lateral Raise is purpose-built for isolated deltoid development and shoulder width in commercial gym environments. Its natural lateral arc guides the arms through a biomechanically correct abduction movement — targeting the medial deltoid with precision while protecting the shoulder joint throughout the full range of motion. Consistent, smooth resistance from the starting position through to peak abduction keeps tension on the deltoids and trapezius with every rep, building the shoulder width and definition essential for a complete upper body physique. The stable, supportive design keeps users correctly positioned throughout the movement, eliminating body lean and momentum and ensuring pure deltoid isolation set after set. Built to commercial standards with a 96 kg weight stack and precision-engineered components, the HS05 handles the demands of high-traffic gym use with reliable, consistent performance every session.

Who It's For
Commercial gyms, hotel fitness centers, corporate wellness facilities, and athletic training centers requiring professional-grade equipment.
Installation
Ships partially assembled. 2 people recommended. Allow 2m × 2m clearance.
Warranty
Commercial Warranty — Contact for Terms. 3 Year Frame, 1 Year Parts, 1 Year Upholstery
Need Guidance?
Call us at 918.706.5186 or contact us online to speak with a DAWG Built equipment specialist.

Color representations may vary slightly due to screen calibration. For a custom color, contact your DAWG Built sales representative.

Frame & Paint Colors
Matte Black
Pearl Black
White
Yellow
Orange
Sand Black
Silver Blue
Silver Grey
Silver Black
Silver Red
Upholstery & Leather
B6 Khaki
B10 Pink
B8 Crimson
B1 Red
B5 Brown
B2 Charcoal
B16 Black
B17 Dark
B12 Carbon
B3 Jet

Reviews

There are no reviews yet.

Be the first to review “HS05 Lateral Raise”

Your email address will not be published. Required fields are marked *

Technical Data

Full Specifications

Model Number
HS05 Lateral Raise
Series
Forge Series
Equipment Type
Pin-Select
Machine Weight
233kg
Weight Stack
96kg+4.6kg
Width
1100 mm
Length
1000 mm
Height
1630 mm
Packing Size
1720×820×420mm
Muscle Group
Deltoids, Medial Deltoid, Lateral Deltoid, Trapezius, Supraspinatus
Frame Colors
10 Standard
Upholstery
10 Options
HS05 Lateral Raise dimensions
Machine Dimensions
Dimensions (W×L×H) 1100×1000×1630mm
Packing Size 1720×820×420mm
Machine Weight 233kg
Weight Stack 96kg+4.6kg
Why DAWG Built

Built Different

Commercial Construction
11-gauge steel frame with CNC-machined pivot points. Built for 10,000+ cycles without performance degradation — because downtime is not an option.
Precision Engineering
Variable-radius cam delivers consistent, smooth resistance through the full range of motion. Biomechanically optimized for maximum muscle engagement.
Low Maintenance
Sealed weight stack housing, self-lubricating cable guide pulleys, and powder-coated frame reduce upkeep in high-traffic commercial facilities.
Full Customization
10 frame paint colors and 10 upholstery options. Custom color matching available on request to match your facility brand.
Ergonomic Design
Multi-position seat and pad adjustments accommodate users of all heights. Each machine's pad density is calibrated for its specific movement pattern.
Wholesale Program
Order 3+ machines and unlock automatic bulk discount. Apply for wholesale partner status for exclusive pricing and dedicated account support.
